ProxiPlate 384-shallow well Plus, white, case of 200

384-well microplate for use in time-resolved fluorescence, luminescence, Alpha, and radiometric assays. This white, polystyrene ProxiPlate™ has shallow wells allowing for lower volumes to be used in assays.

For research use only. Not for use in diagnostic procedures.

Product Variants
Part number: 6008280
Unit Size: Case of 50
List price: USD 562.10
Your price:
USD 0.00
USD 562.10 /each
Part number: 6008289
Unit Size: Case of 200
List price: USD 1,877.00
Your price:
USD 1,877.00
USD 1,877.00 /each

Overview

ProxiPlate is Revvity's shallow-well microplate, offering closer proximity to analyzer's detectors. Designed to miniaturize your assay and utilize cost reduction advantages.

Leveraging years of assay and instrument experience in plate detection, Revvity designs better microplates better performance that guarantees better results all Revvity applications.

Packaging Notes:
  • Cases of 50 are packaged as 2 sleeves of 25 plates each. Each sleeve as 5 wraps with 5 plates.
  • TC-treated cases of 50 are packaged as 50 individually bagged and sealed lidded plates.
  • TC-treated cases of 160 are packaged as 8 sleeves of 20 lidded plates each. Each sleeve as 5 wraps of 4 lidded plates.
  • Cases of 200 are packaged as 8 sleeves of 25 plates each. Each sleeve as 5 wraps with 5 plates.
  • TC-treated cases of 200 are packaged as 8 sleeves of 25 plates each. Each sleeve as 5 wraps with 5 plates. Lids are not included but can be ordered separately as Cat. No. 6005619 96-well plates or Cat. No. 6007619 384-well plates.

Additional product information

Well plate dimensions

Well format: 384-well

Description Specification
Number of rows 16
Number of columns 24
Well volume 28 µL
Recommended working volume 10 µL- 20 µL
Height (mm) 14.35
Length (mm) 127.76
Width (mm) 85.48
Well diameter (mm) 3.3
Well depth (mm) 5.3
A1 to top offset (mm) 8.99
A1 to side offset (mm) 12.13
Well-to-well spacing (mm) 4.5





Specifications

Color
White
Well Format
Well Shape
Shallow-well
Application
Radiometric
Research
Automation Compatible
Yes
Brand
ProxiPlate
Coating Treatment
Untreated
Detection Method
Alpha
Luminescence
Radiometric
Time-Resolved Fluorescence (TRF & TR-FRET)
Format
Microplates
Material
Polystyrene
Sterility
Non-Sterile
Unit Size
Case of 200
